Pulsated Dust Collector Center

  • UNDER THE ACTION OF THE CENTRIFUGAL BLOWER, THE DUST-CONTAINING AIRFLOW ENTERS THE DUST COLLECTOR FROM THE SUCTION PIPE, AND THE DUST IS SEPARATED AND REMOVED BY THE STRONG INTERCEPTION EFFECT OF THE BAG FILTER MATERIAL INSIDE THE MACHINE.
  • THE FILTER BAG IS VIBRATED BY THE PULSE CLEANING DEVICE INSIDE THE DUST REMOVER, SO THAT THE DUST ADHERING TO THE SURFACE LOOSELY FALLS OFF, THEREBY ACHIEVING THE CLEANING EFFECT.
  • THE DUST COLLECTOR OF THIS SYSTEM IS A NEGATIVE PRESSURE EXTERNAL FILTER OPERATION MODE.
Model RXC3011M RXC3055M
Dust collect bag size Φ136mm*1000 Φ136mm*1000
Cage type bag size Φ136mm*1000 Φ136mm*1000
Dust collect bag qty 56pcs 30pcs
Dust collect bag total area 24㎡ 13㎡
Air capacity 8000-10000m³ /h 4000-5000m³ /h
Dust entry requirements No fire source No fire source
Output dust concentration ≤60mg/ m³ ≤60mg/ m³
Compressed air consumption 0.8m³/min 0.8m³/min
Weight 1360kg 950kg
Overall size 2600*1800*2600mm 1800*1400*2600mm
Air blower Noise (1 meter away)  80 dB(A)(after connecting with pipes) 80 dB(A)(after connecting with pipes)
